Sapphire Wafer
Our high quality sapphire wafers are available in standard diameters from 2” to 150mm. The can be single or double side polished in C, A, and R plane orientations.
What is a Sapphire Wafer?
A Sapphire Wafer is a thin slice of synthetic sapphire (Al₂O₃), typically grown using the Kyropoulos (Kr) technique. It serves as a substrate material and foundational layer, upon which other semiconductor materials are deposited or grown.
Sapphire (Al₂O₃) is a hexagonal crystal, and its orientation significantly influences the wafer’s optical, mechanical, thermal, and electrical properties. The orientation is defined by the alignment of the wafer surface relative to the crystal axes, commonly expressed as C-plane (0001), R-plane (11-02), and A-plane (11-20).
Key Features of Sapphire Wafers
- PRIME grade high quality sapphire wafer
- Sapphire wafers with C, A, and R plane crystal orientation
- 2” to 150mm wafers available
- Kr grown with high purity, 99.998%
- Single or both sides polished and EPI finish available
- Very low roughness and defect free for EPI growth
- Supply and Shipment Worldwide from Stock or on short lead times
- Buy Sapphire wafers online
Buy Sapphire Wafers online
We maintain a large inventory of different Sapphire wafer types for rapid dispatch. Browse our “Online Semiconductor Wafer Store” to view current stock and technical specifications.
- Extensive Inventory: A wide selection wafer sizes & thicknesses
- Fast Global Shipping: Rapid dispatch from our UK warehouse
- Custom Processing: Oxide and nitride deposition, wafer thinning and more
- Expert Support: Technical advice to help you select the right wafer
- No Minimum Order: Perfect for both R&D and production environments
- Quality Assurance: All wafers undergo rigorous inspection processes
Delivering PRIME grade, Kr grown Sapphire Wafers
Inseto specialise in supplying PRIME grade, Kr grown sapphire wafers with exceptional purity and surface finish. The wafers are ideal for demanding semiconductor and optoelectronic applications, including HB-LED production, high-voltage devices, and silicon epitaxy.
Why are Sapphire Wafers used to manufacture Semiconductor Devices?
Sapphire wafers offer numerous benefits, making them the preferred choice for semiconductor fabrication:
- Durability and Chemical Resistance: Sapphire withstands extreme temperatures (up to 2000°C) and aggressive chemicals used in semiconductor manufacturing, outperforming materials like quartz in longevity and reliability.
- Excellent Lattice Match: Sapphire wafers offer a good lattice match with materials such as Gallium Nitride (GaN), Aluminium Nitride (AlN), and Silicon (Si), helping to minimise strain and reduce crystal defects during epitaxial growth.
- High Thermal Conductivity: Its ability to dissipate heat efficiently makes it ideal for high-power and high-frequency devices, especially those operating in harsh environments.
- Electrical Insulation: Sapphire is an excellent electrical insulator, which helps reduce parasitic capacitance and leakage currents in integrated circuits.
- Optical Transparency: This property makes sapphire suitable for optical components, including windows and substrates in optoelectronic devices.
Sapphire Wafers shipped and used worldwide
Our high-quality Sapphire Wafers are shipped and used worldwide by University and Industrial Research, Manufacturing and equipment manufacturers. Sapphire wafers can be purchased online via the Inseto Wafer Store.
Got a Question About Sapphire Wafers?
Curious about semiconductor materials and how to choose the right silicon wafer? Explore our “Semiconductor Wafer Selection Guide” for expert insights. You’ll also find a wealth of information in our free “Knowledge Base“, covering semiconductor processes, technologies, and more.
Choosing the right Sapphire wafer can be complex, especially if you’re unsure about specifications or material types. That’s why Inseto offers expert guidance to help you make the best choice for your application.
Whether you’re developing a new product or refining an existing process, Inseto’s team of experts is here to help. From selecting the right semiconductor wafer to onsite training, we provide technical guidance, documentation, and support for your production needs.
Applications for Sapphire Wafers
Key Applications
Sapphire wafers are used extensively for HB-LED production due to the good lattice match between III-V and II-VI materials and Sapphire. It also has high resistance to thermal shock and can produce low stress layers.
Sapphire is also a good substrate for Si EPI growth due to very low defectivity and low loss properties. It is also widely used in the fabrication of high voltage power and frequency devices where the thermal conductance, very stable dielectric constant, and low loss properties enable it to operate reliably in very harsh conditions. It also has high optical transmission across a wide range of wavelengths.
Sapphire Wafers Product Range
Wafer Specifications
- Sapphire Wafer sizes from 2” to 150mm, from inventory
- Very high quality low defectivity and tight TTV and flatness
- High purity 99.998%
- Single and double sided polished available
- C, A, and R plane orientations
- Small lot sizes and Laser marking of wafers available
- Short lead-time for delivery
